Suitable for all LED fixtures ranging from 6-25W, including emergency lighting such as LED fluorescent lamps, LED tubes, and LED down lights;
The battery adopts a 11.1V ternary lithium battery pack, a 12V nickel cadmium or nickel hydrogen battery pack, or a 12.8V lithium iron phosphate battery pack
Full power emergency lighting, with emergency lighting brightness equal to the brightness of mains lighting;
International routes, three color indicator lights, and detection buttons;
No-load protection, constant current limited voltage charging, and dual protection board for charging and discharging ensure the safety of lithium battery pack use;
Strictly follow the wiring diagram to connect the circuit, and do not open the cover arbitrarily;
Users can regularly check the discharge status of the inverter, that is, cut off the mains power supply and use batteries to discharge lighting until automatic termination;
Technical parameters:
Input: AC90-280V/50HZ-60HZ
Output: AC/DC 90-280V/50HZ-60HZ
Power: 6-25W
Emergency time: 1-3 hours, or set according to customer requirements;
Battery: 12.8V lithium iron phosphate battery 11.1V lithium-ion battery 12V nickel battery pack
Charging current: 200mA
Emergency power supply size/length * width * thickness=168 * 38 * 28mm
Weight=300g
